PBM Lub cev muaj zog thiab kiv cua (Suzhou) Co., Ltd. Nrog kev paub ntau, peb tau cog lus los muab cov khoom lag luam zoo siab nrog cov nqi sib tw. Yog hais tias koj yuav mus yuav bulk premium φ50x198mm dc cross flow kiv cua pc50b24198b, txais tos kom tau txais pricelist los ntawm peb lub hoobkas.
Cov Cwj Pwm
|
1-1 |
Rated Voltage |
24 VDC |
|
1-2 |
Kev khiav hauj lwm voltage |
16-28 VDC |
|
1-3 |
Rated Ceev |
2400 RPM |
|
1-4 |
Input Tam sim no |
0.28 A |
|
1-5 |
Lub zog nkag |
6.72 W |
|
1-6 |
Cua Flow |
88.28 CFM / 150 m3/H |
|
1-7 |
Static Siab |
4.59 mmH2O / 45 Pa |
|
1-8 |
Suab nrov nrov |
43 dB (A) |
|
1-9 |
Lub Neej Cia Siab |
50,000 teev (L10) Ntawm 40℃chav, av noo 15% ~ 65% RH. |
|
1-10 |
Rwb thaiv tsev Class |
Chav B |
|
1-11 |
Kev tiv thaiv lub cev muaj zog |
Xauv rotor tiv thaiv Kev tiv thaiv polarity Tsis siv neeg restart muaj peev xwm |
|
1-12 |
Tswj ceev |
Tswj input 0 ~ 10VDC / PWM |
|
1-13 |
Hom kev tiv thaiv |
IP44 |
|
1-14 |
Teeb liab tso zis |
FG (Frequency Generator) |
Mechanical Cim
|
2-1 |
Dimension |
70mm X 70mm X 266mm (saib qhov loj me) |
|
2-2 |
Khoom siv ntawm Impeller |
Aluminium alloy |
|
2-3 |
Number of Blades |
22 |
|
2-4 |
Bearing System |
NMB pob bearing |
|
2-5 |
Hlau Hlau |
Liab, Dub, Dawb AWG22# |
Environmental Cwj Pwm
|
3-1 |
Ua haujlwm kub |
-25℃rau 60 degree |
|
3-2 |
Cia kub |
-40℃rau 75 degree |
|
3-3 |
Kev khiav dej num |
5% mus rau 90% RH |
|
3-4 |
Cia Humidity |
5% mus rau 95% RH |
Performance Curve
Input Voltage ---- Ua haujlwm voltage (24 VDC)
Qhov kub thiab txias ---- Chav ntsuas kub
Humidity -------- 65% RH
Test nrug----- 1m
Daim duab kos duab
Nco tseg:
Kev sib txuas kab 3X (Liab, Dub, Dawb AWG22#);
Liab=+24VDC, Dawb=0-10VDC, Xiav=GND.
