PBM Tsav thiab Ntxuam (Suzhou) Co., Ltd. yog ib qho ntawm feem txhim khu kev qha manufacturers thiab lwm tus neeg ntawm 160mm ec-ac ib leeg inlet blower ps3n160b2em nyob rau hauv Suav teb. Nrog kev paub ntau, peb tau cog lus los muab cov khoom lag luam zoo siab nrog cov nqi sib tw. Yog hais tias koj yuav mus yuav bulk premium 160mm ec{10}}ac ib leeg inlet blower ps3n160b2em, txais tos kom tau txais pricelist los ntawm peb lub hoobkas.
PBM yog tus kws tshaj lij hauv kev tsim kho thiab tsim cov kiv cua EC / DC zoo tshaj plaws thiab cov kev daws teeb meem ntse airflow. Los ntawm kev txhawb nqa cov teeb liab tawm ceev (FG), cov kiv cua pab saib xyuas tej thaj chaw deb los ntawm kev saib xyuas ib puag ncig (EMS) thiab kev sib koom ua ke. Lawv tuaj yeem ua tau raws li cov cua ntws tsis tu ncua lossis qhov tsis tu ncua ntawm cov txheej txheem tswj kev ua haujlwm siab ntawm cov dehumidifiers thaum ua ke nrog 0-10V / PWM ceev tswj, ua kom txaus siab rau ob lub hom phiaj ntawm qhov tseeb dehumidification thiab ruaj khov airflow nyob rau hauv cov xwm txheej nrog cov av noo thiab kub. PBM yog koj lub chaw muab kev pabcuam rau lub tshuab cua dehumidifier thiab purification kev daws teeb meem, tsis yog tus tsim cov kiv cua.
Cov Cwj Pwm
|
1-1 |
Rated Voltage |
230 VAC ua |
|
1-2 |
Ntau zaus |
50/60 Hz |
|
1-3 |
Kev khiav hauj lwm voltage |
184-270 VAC |
|
1-4 |
Rated Ceev | 1950 RPM |
|
1-5 |
Input Tam sim no |
1.2 A |
|
1-6 |
Lub zog nkag |
170 W |
|
1-7 |
Cua Flow |
404.89 CFM / 688 M³ / H |
|
1-8 |
Static Siab |
3.24 inH₂O / 810 Pa |
|
1-9 |
Suab nrov nrov |
72 dB (A) |
|
1-10 |
Lub neej expectancy |
50,000 teev (L10) Ntawm 40℃chav, av noo 15% ~ 65% RH. |
|
1-11 |
Rwb thaiv tsev Class |
Chav B |
|
1-13 |
Kev tiv thaiv lub cev muaj zog |
Xauv rotor tiv thaiv Kev tiv thaiv polarity Tsis siv neeg restart muaj peev xwm |
|
1-14 |
Tswj ceev |
Tswj input 0 ~ 10VDC / PWM |
|
1-15 |
Hom kev tiv thaiv |
IP44 |
|
1-17 |
Teeb liab tso zis |
FG (Frequency Generator) |
Mechanical Cim
|
2-1 |
Dimension |
220mm X 245mm X 130mm (saib qhov loj me) |
|
2-2 |
Khoom siv ntawm Impeller |
Galvanized hlau plhaub |
|
2-3 |
Number of Blades |
38 |
|
2-4 |
Bearing System |
NMB pob bearing |
|
2-5 |
Hlau Hlau |
AC (AWG 20 #), DC (AWG 22 #) |
Environmental Cwj Pwm
|
3-1 |
Ua haujlwm kub |
-25℃rau 60 degree |
|
3-2 |
Cia Kub |
-40℃rau 75 degree |
|
3-3 |
Kev khiav dej num |
5% mus rau 90% RH |
|
3-4 |
Cia Humidity |
5% mus rau 95% RH |
Performance Curve
Kev kuaj mob:
Input Voltage ---- Ua haujlwm voltage (230VAC / 50Hz)
Qhov kub thiab txias ---- Chav ntsuas kub
Humidity -------- 65% RH
Daim duab kos duab
Nco tseg:
1.Connection kab: AC (3 × AWG20 #), DC (4 × AWG22 #)
2.AC: Brown=Txoj kab nyob, Xiav=Null Line, Ntsuab & Daj= Tiv thaiv Earthing;
3.DC: Liab=Voltage Output +10VDC, Yellow=0-10VDC/PWM, White=FG, Blue=GND;
Cim npe nrov: 160mm ec-ac ib leeg inlet blower ps3n160b2em, Tuam Tshoj 160mm ec-ac ib leeg inlet blower ps3n160b2em manufacturers, lwm tus neeg, Hoobkas
